PE1V31018

Overview

The PE1V31018 is a Voltage Controlled Oscillator (VCO) manufactured by Pasternack. It operates within a frequency range of 850 MHz to 890 MHz. The device provides an output power of +8 dBm with a typical phase noise of -99 dBc/Hz. It features a tuning voltage range from 0 V to 5 V. The component utilizes SMA connectors for interface connections and is supplied in a module package configuration.

Feature Summary

• Provides stable voltage-controlled oscillation across the specified microwave frequency band
• Delivers consistent output power levels suitable for signal generation applications
• Incorporates low phase noise characteristics to maintain signal integrity
• Features standard SMA interfaces for straightforward integration into RF systems

Applications

• Wireless communication systems requiring precise frequency synthesis
• Test and measurement equipment needing stable local oscillator signals
• Radar systems utilizing microwave frequency generation
• Instrumentation requiring low phase noise signal sources

Procurement Notes

Verify the specific datasheet revision and electrical tolerances against current project requirements before procurement. Confirm that the SMA connector polarity and module dimensions align with the intended PCB layout or chassis design. Ensure that the supply voltage and tuning voltage ranges are compatible with the control circuitry available in the system architecture to guarantee proper operation.

Selection Notes

Select this component when a fixed frequency range between 850 MHz and 890 MHz is required with moderate output power. Consider the -99 dBc/Hz phase noise specification for applications sensitive to spectral purity. Evaluate the SMA interface compatibility against existing system connectors. Compare the 0 V to 5 V tuning range against available control voltages in the design to ensure adequate frequency modulation capability without additional amplification.

Part Context

This part belongs to Pasternack's Voltage Controlled Oscillator series, designed for reliable microwave frequency generation. The PE1V31018 specifically targets applications in the UHF to L-band spectrum. It represents a standardized solution for engineers needing compact, pre-tuned oscillator modules with defined performance metrics for integration into larger RF assemblies.

Replacement Considerations

No public confirmed substitute part numbers are available for this specific model.
