PE6212

Overview

The Pasternack PE6212 is a general-purpose RF IC termination designed for high-power applications. It features an SMA female input connector and supports a frequency range from 0 Hz to 18 GHz. The component is rated for a maximum power handling capacity of 50 Watts. This load serves as a broadband termination solution suitable for testing and measurement environments requiring stable impedance matching across a wide spectrum.

Feature Summary

• Provides a 50-ohm termination for RF signal paths
• Supports broadband operation up to 18 GHz
• Rated for 50 Watts continuous power handling
• Utilizes an SMA female interface for easy integration

Applications

• RF circuit testing and characterization
• Signal generator output termination
• Amplifier load testing
• Vector network analyzer calibration references

Procurement Notes

Verify the specific datasheet version for precise VSWR and power derating curves at elevated frequencies. Confirm that the SMA female interface matches your test fixture requirements. Ensure thermal management provisions are adequate for sustained 50W operation, as heat dissipation affects long-term reliability in enclosed setups.

Selection Notes

Select this model when a broadband 50-ohm load is required up to 18 GHz with 50W capacity. Compare against PE6211 if a male SMA interface is preferred instead. Consider thermal resistance specifications if mounting directly to PCBs without heatsinks. Verify frequency coverage meets the highest harmonic or intermodulation product frequencies present in the application.

Part Context

This component belongs to Pasternack's series of medium-power RF loads. These terminations are engineered for stability and low reflection across microwave frequencies. The PE6212 variant specifically addresses applications needing female SMA connectivity, distinguishing it from male-input counterparts within the same product family.

Replacement Considerations

PE6211 is a direct functional substitute offering identical electrical performance but with an SMA male connector instead of female. Ensure mechanical compatibility with existing fixtures before swapping between male and female variants.
