PE6213

Overview

The PE6213 is a general-purpose RF IC termination module manufactured by Pasternack. It functions as a medium power load with a rated capacity of 50 Watts. The component operates across a frequency range from 0 Hz to 18 GHz. This module provides a stable impedance termination for radio frequency circuits within the specified bandwidth.

Feature Summary

• Provides a 50 Watt power handling capability for RF applications
• Operates effectively from DC up to 18 GHz frequency range
• Designed as a general-purpose RF IC termination module

Applications

• RF circuit testing and characterization
• Signal generator output termination
• Amplifier load matching

Procurement Notes

Verify the specific datasheet version for the PE6213 to confirm mechanical dimensions and connector types. Ensure the operating environment remains within the 50 Watt thermal limits. Confirm that the 0-18 GHz specification aligns with the intended application bandwidth requirements before procurement.

Selection Notes

Select this module when a broadband termination up to 18 GHz is required. The 50 Watt rating suits moderate power levels. Consider thermal management solutions if continuous operation near maximum power is anticipated. Verify compatibility with existing test equipment interfaces.

Part Context

This component belongs to Pasternack's RF IC termination series. It serves as a passive load for high-frequency signal paths. The design supports general-purpose use in laboratory and industrial RF environments requiring reliable impedance matching.

Replacement Considerations

No public substitute part numbers are documented.
