PE6224

Overview

The Pasternack PE6224 is a coaxial cable assembly designed for high-frequency signal transmission. It utilizes RG-316/U cable construction, offering flexibility and durability in compact spaces. The assembly features SMA connectors at both ends, providing reliable RF connections with low insertion loss. This component supports frequencies up to 6 GHz, making it suitable for various electronic applications requiring consistent signal integrity.

Feature Summary

• Flexible RG-316/U cable construction for easy routing in tight spaces
• SMA male-to-male connector configuration for standard interface compatibility
• Optimized for minimal signal attenuation across wide bandwidths

Applications

• Test and measurement equipment interconnections
• Wireless communication system components
• Medical imaging device signal paths

Procurement Notes

Verify connector gender and cable length requirements before ordering. Ensure environmental conditions match the cable's operating temperature range. Confirm impedance specifications align with system design needs. Check for any specific certification requirements relevant to your industry application.

Selection Notes

Consider the flexibility of RG-316/U when planning installation routes. Evaluate frequency requirements against the 6 GHz upper limit. Assess physical space constraints due to the small form factor. Determine if bulkhead mounting options are necessary for panel integration.

Part Context

This model belongs to Pasternack's line of precision RF cable assemblies. It complements other SMA-based solutions by offering a flexible alternative to rigid cables. The product series focuses on maintaining signal quality in demanding environments while providing ease of use for technicians and engineers alike.
