PE6TR1174

Overview

The Pasternack PE6TR1174 is a coaxial RF terminator designed for high-frequency applications. It features an SMA female input interface and is housed in a durable stainless steel body. The component operates as a 2-watt RF load with a frequency range extending up to 18 GHz. This termination device provides a stable impedance match for signal testing and measurement environments.

Feature Summary

• Stainless steel construction for mechanical durability
• SMA female connector interface
• Rated for 2-watt power handling

Applications

• RF signal path termination
• Test and measurement equipment loads
• High-frequency circuit characterization

Procurement Notes

Verify the specific datasheet version for precise dimensional tolerances and environmental operating limits. Confirm that the SMA female interface matches the system requirements. Ensure the 2-watt power rating aligns with the expected signal levels in the application to prevent thermal damage during operation.

Selection Notes

Select this model when a robust, stainless steel terminated load is required for frequencies up to 18 GHz. The SMA female interface dictates compatibility with standard SMA male connectors. Consider the physical size and mounting constraints associated with the stainless steel housing design.

Part Context

This component belongs to the Pasternack Coaxial RF Terminations series. It serves as a dummy load to absorb RF energy without reflection. The product is categorized under RF Interconnects and is distinct from cable assemblies or adapters within the manufacturer's portfolio.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Users should verify interface compatibility and power ratings when considering alternative terminators from other manufacturers.
