Product Detailed Parameters
- Description：2 Watt RF Load With Chain Up to
- Series：-
- Mfr：Pasternack
- Package：Retail Package
- Function：Termination
- Frequency：0Hz ~ 18GHz
- RF Type：Radar
- Secondary Attributes：2W
- Mounting Type：Chassis Mount
- Package / Case：TNC In-Line Module
- Supplier Device Package：-
- Grade：-
- Qualification：-
Download product information
Overview
The PE6TR1174C is an RF terminator manufactured by Pasternack, designed for high-frequency signal termination applications. It features a TNC female input connector and is housed in a stainless steel body. The component supports a power rating of 2 Watts and operates effectively across a frequency range from 0 Hz to 18 GHz. This device belongs to the Coaxial RF Terminations series and is classified under RF Interconnects. The unit weighs approximately 13.608 grams and is packaged in bulk quantities.
Feature Summary
- Provides reliable signal termination with a 2-watt power handling capacity
- Operates across a wide frequency spectrum extending up to 18 GHz
- Constructed with a durable stainless steel housing for environmental resilience
Applications
- RF test and measurement setups requiring precise impedance matching
- Signal chain termination in microwave and radar systems
- Laboratory equipment calibration and verification processes
Procurement Notes
Verify the specific datasheet version for the PE6TR1174C to confirm current manufacturing status and compliance certifications. Check distributor availability as stock levels may vary. Ensure the TNC female interface matches your system requirements before ordering. Confirm that the 2-watt power rating aligns with your application's thermal and electrical constraints.
Selection Notes
Select this model when a robust, wideband RF load is needed for frequencies up to 18 GHz. The TNC female interface is suitable for standard coaxial connections. Consider the stainless steel construction for durability in demanding environments. Compare against other Pasternack terminators if higher power or different frequency ranges are required.
Part Context
This component is part of Pasternack's Coaxial RF Terminations series, which includes various loads for different connector types and frequency ranges. It serves as a passive termination device within the broader category of RF interconnects. The product line focuses on providing stable impedance characteristics for high-frequency signal integrity.
Replacement Considerations
Consult official documentation for direct substitutes. Other models in the PE6TR series may offer similar specifications with different connector interfaces or frequency limits.
