PE7014-6

Overview

The Pasternack PE7014-6 is a fixed attenuator designed for RF applications up to 18 GHz. It provides a precise attenuation value of 6 dB with N Male to N Female connectors. The unit features an aluminum heatsink body with black anodized finish, rated for 5 Watts power handling.

Feature Summary

• Fixed 6 dB attenuation
• N Male to N Female interface
• Aluminum heatsink construction
• Black anodized finish

Applications

• RF signal testing and measurement
• Signal level reduction in transmission lines
• Impedance matching networks
• Power monitoring setups

Procurement Notes

Verify the exact model number against official Pasternack documentation to ensure correct attenuation value and connector type. Confirm frequency range and power rating requirements match application needs before ordering.

Selection Notes

Select this component when a fixed 6 dB loss is required at frequencies up to 18 GHz. Ensure system power levels do not exceed the 5 Watt rating. Consider thermal management due to the heatsink design.

Part Context

This part belongs to Pasternack's fixed attenuator series. It serves as a passive component for controlling signal amplitude in RF circuits without introducing significant phase shift or distortion within its specified bandwidth.

Replacement Considerations

Check for compatible N-type fixed attenuators from other manufacturers if lead times are critical. Ensure replacement parts meet the same 6 dB tolerance and 18 GHz frequency specifications.
