PE7017-30

Overview

The Pasternack PE7017-30 is a fixed directional attenuator featuring N Male to N Female connectors. It provides a nominal attenuation of 30 dB with an accuracy of ±1.5 dB across a frequency range of DC to 18 GHz. The unit maintains a maximum VSWR of 1.45:1 and supports a maximum input power of 50 Watts. Constructed with a black anodized aluminum heatsink body, it operates within a temperature range of -65°C to +125°C.

Feature Summary

• Directional signal attenuation capability for precise RF power control
• Integrated aluminum heatsink body for thermal management
• Black anodized finish for corrosion resistance and durability

Applications

• RF test and measurement setups requiring fixed signal reduction
• Protection of sensitive receiver components from high power levels
• Signal conditioning in microwave communication systems up to 18 GHz

Procurement Notes

Verify the specific datasheet version for the PE7017-30 to confirm mechanical dimensions and connector specifications. Ensure the application environment stays within the stated -65°C to +125°C operating range. Confirm that the 50 Watt power rating aligns with system requirements before integration.

Selection Notes

Select this component when a fixed 30 dB attenuation is required at frequencies up to 18 GHz. The N-type interface ensures compatibility with standard coaxial systems. Consider the heatsink design for applications where thermal dissipation is critical for maintaining performance stability.

Part Context

This part belongs to Pasternack's line of fixed directional attenuators designed for high-frequency applications. It utilizes robust N-type connectors to ensure reliable connections in demanding environments. The product is engineered for consistent performance across a wide bandwidth.

Replacement Considerations

Pasternack PE7019-30 offers similar electrical specifications but features a different body construction.
