PE7022-6

Overview

The Pasternack PE7022-6 is a fixed attenuator module designed for RF applications. It provides a nominal attenuation of 6 dB with a maximum frequency range of 1.5 GHz. The device features SMA male to SMA female connectors and operates at a system impedance of 50 Ohms. It is rated for a power handling capacity of 100 Watts at the stated attenuation value. The unit utilizes a directional aluminum heatsink construction finished in black.

Feature Summary

• Directional aluminum heatsink construction for thermal management
• SMA male to SMA female connector interface
• Fixed 6 dB attenuation value

Applications

• RF signal level reduction
• Impedance matching in microwave circuits
• Test and measurement equipment

Procurement Notes

Verify the specific datasheet version for the PE7022-6 to confirm current manufacturing status and detailed electrical tolerances. Ensure that the required power rating of 100 Watts aligns with the operational environment, as exceeding this limit may damage the component. Confirm connector gender and orientation requirements prior to integration into the assembly.

Selection Notes

Select the PE7022-6 when a fixed 6 dB attenuation is required within a 50 Ohm system up to 1.5 GHz. This model is suitable for high-power applications due to its 100 Watt rating and integrated heatsink. Consider the SMA interface compatibility with existing cabling and ensure the directional design meets the signal flow requirements of the circuit.

Part Context

This component belongs to the Pasternack series of RF attenuators. It serves as a passive interconnect device used to reduce signal amplitude without altering the impedance characteristics of the transmission line. The fixed nature of the attenuation makes it distinct from variable or step attenuators, providing a consistent loss profile across the specified frequency band.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Users should verify compatibility with equivalent models from other manufacturers based on attenuation value, frequency range, power rating, and connector type.
