PE7089-9

$120.42

Description：9DB ATTN 2.4MM 1W 50GHZ
Series：-
Mfr：Pasternack
Package：Bag

SKU:2950a04d0f60 Category: Attenuators Brand: Pasternack

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：9DB ATTN 2.4MM 1W 50GHZ
Series：-
Mfr：Pasternack
Package：Bag
Attenuation Value：9dB
Frequency Range：0 Hz ~ 50 GHz
Power (Watts)：1W
Impedance：50 Ohms
Grade：-
Qualification：-
Package / Case：Module

Download product information

PE7089-9

Overview

The Pasternack PE7089-9 is a fixed RF attenuator designed for high-frequency applications. It features a 2.4mm male connector on one side and a 2.4mm female connector on the other, providing a precise attenuation value of 9 dB. The component operates within a frequency range extending up to 50 GHz. It is rated for a power handling capacity of 1 Watt at the stated attenuation level. The unit utilizes a passivated stainless steel body for durability.

Feature Summary

Fixed 9 dB attenuation value
2.4mm male to female interface
Operates up to 50 GHz
Passivated stainless steel construction

Applications

Microwave test and measurement setups
Signal conditioning in high-frequency circuits
RF system calibration equipment

Procurement Notes

Verify the specific connector gender configuration matches the design requirements before ordering. Confirm that the 1 Watt power rating aligns with the maximum signal levels present in the application circuit. Ensure compatibility with 2.4mm mating interfaces to maintain signal integrity and prevent mechanical damage during installation.

Selection Notes

Select this model when a precise 9 dB reduction is required in systems operating near or above standard microwave frequencies. The 2.4mm interface supports higher bandwidths compared to larger connectors. Consider the 1 Watt power limit when evaluating thermal management needs for continuous wave signals.

Part Context

This component belongs to the family of fixed coaxial attenuators manufactured by Pasternack. These devices are engineered to provide stable impedance matching and consistent attenuation across wide bandwidths. The 2.4mm series is specifically tailored for applications demanding performance beyond the capabilities of smaller SMA or N-type connectors.

Replacement Considerations

Direct substitutes must match the 9 dB attenuation value, 2.4mm connector type, and 50 GHz frequency limit. Verify power ratings and physical dimensions to ensure interchangeability without modifying the host assembly.
