PE7091-3

Overview

The Pasternack PE7091-3 is a coaxial cable assembly featuring SMA male to SMA male connectors. It utilizes RG142B/U dielectric material and a silver-plated copper center conductor with PTFE insulation. The assembly operates within a frequency range of DC to 18 GHz, offering a nominal impedance of 50 Ohms. Key electrical specifications include a maximum VSWR of 1.4:1 and an insertion loss of approximately 0.6 dB at 1 GHz. The unit supports a maximum power handling of 50 Watts and maintains a shielding effectiveness exceeding 100 dB.

Feature Summary

• SMA male to SMA male connector configuration for reliable signal transmission
• RG142B/U construction providing durability and consistent performance
• Silver-plated copper center conductor ensuring low resistance
• PTFE dielectric material supporting high-frequency operation up to 18 GHz

Applications

• RF test and measurement equipment interconnections
• Wireless communication system component linking
• Aerospace and defense radar systems integration

Procurement Notes

Verify the specific length requirements against the datasheet, as this model denotes a standard fixed length. Confirm connector gender and interface type match your system ports. Ensure environmental conditions align with the specified operating temperature range. Check for any specific RoHS compliance documentation if required by your procurement policy. Validate that the power handling capabilities meet your application's peak and average power demands before finalizing the order.

Selection Notes

Select this assembly when a rigid, durable coaxial link between two SMA female ports is required. The RG142B/U cable offers superior mechanical strength compared to flexible alternatives like RG58. Consider the 18 GHz bandwidth limit for high-frequency applications. The 50 Ohm impedance matches standard RF systems. Evaluate the fixed length constraint against routing needs in your chassis or panel design.

Part Context

This component belongs to Pasternack's line of precision coaxial cable assemblies designed for demanding RF environments. The PE7091 series typically features robust SMA connectors suitable for repeated mating cycles. These assemblies are engineered to maintain signal integrity across wide bandwidths. The specific model integrates standardized materials to ensure consistency in electrical performance and physical reliability for industrial use cases.

Replacement Considerations

Direct substitutes may include other SMA male-to-male assemblies using RG142B/U cable from different manufacturers. Verify that replacement parts match the 50 Ohm impedance and 18 GHz frequency range. Ensure connector dimensions and keying mechanisms are compatible with existing fixtures. Cross-reference VSWR and insertion loss specifications to maintain system performance levels.
