PE70A1038

Overview

The PE70A1038 is a high-power RF attenuator module manufactured by Pasternack. It features Type N female connectors on both input and output ports, ensuring compatibility with standard high-power RF infrastructure. The device provides a maximum attenuation of 100 dB and is rated for a continuous power handling capacity of 100 Watts. It operates effectively within a frequency range from DC to 3 GHz. This component is designed as a robust module for signal reduction in demanding RF environments.

Feature Summary

• Provides up to 100 dB of maximum signal attenuation
• Rated for 100 Watts of continuous power handling
• Operates across a frequency spectrum from DC to 3 GHz
• Utilizes durable Type N female connector interfaces

Applications

• High-power RF test and measurement setups
• Signal level reduction in transmitter chains
• RF system protection against excessive power levels
• Laboratory calibration and equipment testing

Procurement Notes

Verify the specific datasheet version when ordering, as manufacturer specifications may be updated. Confirm that the required attenuation value aligns with the 100 dB maximum rating. Ensure that the operating frequency does not exceed the 3 GHz limit. Check for any specific mounting or thermal management requirements associated with the 100 Watt power rating before integration into the final assembly.

Selection Notes

Select this model when high power handling is critical, as it supports 100 Watts compared to lower-rated alternatives. The Type N interface is suitable for applications requiring robust mechanical connections. Consider the physical dimensions of the module to ensure it fits within the available space. Verify that the frequency range up to 3 GHz meets the system's operational bandwidth requirements without significant performance degradation.

Part Context

This component belongs to the Pasternack Attenuators category, specifically designed for RF and wireless applications. It serves as a passive device to reduce signal amplitude without introducing significant distortion. The module format allows for easy integration into rack-mounted systems or custom test fixtures. It complements other Pasternack RF components by providing reliable signal control in high-energy circuits.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. When selecting an alternative, ensure the replacement matches the 100 Watt power rating and Type N connector type. Verify that the new component offers comparable attenuation stability and frequency response up to 3 GHz. Consult manufacturer cross-reference guides for potential equivalents if direct substitution is required.
