PE70A2007

Overview

The PE70A2007 is a voltage-controlled attenuator manufactured by Pasternack, designed for RF signal amplitude reduction. It operates within the 8 GHz to 12 GHz frequency range and provides a maximum attenuation of 30 dB. The device utilizes SMA female connectors for interconnection and features a field-replaceable design for maintenance efficiency. This component is part of the active voltage variable attenuator series, engineered to handle specific RF power levels while maintaining signal integrity across its defined bandwidth.

Feature Summary

• Field-replaceable construction facilitates maintenance and reduces downtime
• Voltage-controlled operation allows for dynamic signal amplitude adjustment
• SMA female interface ensures compatibility with standard RF systems

Applications

• RF test and measurement equipment requiring precise signal control
• Wireless communication systems needing variable gain stages
• Radar systems utilizing high-frequency signal processing

Procurement Notes

Verify the specific datasheet version and connector type compatibility before integration. Confirm that the voltage control requirements align with your system's power supply capabilities. Ensure the operating frequency range matches your application needs. Check for any specific handling instructions related to the field-replaceable components. Validate environmental specifications against your deployment conditions.

Selection Notes

Select this model when variable attenuation is required in the 8-12 GHz band. Consider the field-replaceable feature for long-term maintenance strategies. Evaluate the voltage control interface against existing system architectures. Compare performance metrics with fixed attenuators if constant loss is sufficient. Assess the SMA connector suitability for your cable infrastructure.

Part Context

This component belongs to Pasternack's RF variable attenuator product line, specifically focusing on voltage-controlled models. It complements other attenuator types such as step and continuously variable units. The series emphasizes reliability and ease of maintenance through modular designs. It serves as a critical element in systems requiring real-time signal level management.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
