PE70A5002

$2,435.49

Description：30 dB With 5 Bit Programmable TT
Series：-
Mfr：Pasternack
Package：Retail Package

SKU:2ff82e50a9d8 Category: Attenuators Brand: Pasternack

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：30 dB With 5 Bit Programmable TT
Series：-
Mfr：Pasternack
Package：Retail Package
Attenuation Value：0dB ~ 30dB
Frequency Range：100 MHz ~ 40 GHz
Power (Watts)：-
Impedance：-
Grade：-
Qualification：-
Package / Case：Module

Download product information

PE70A5002

Overview

The PE70A5002 is a programmable step attenuator manufactured by Pasternack, utilizing a 2.92mm connector interface. It provides a total attenuation range of 30 dB with a step resolution of 1 dB. The device operates at a system impedance of 50 Ohms and features TTL control for programmability. This component is designed for applications requiring precise RF signal adjustment within high-frequency environments.

Feature Summary

Programmable attenuation control via TTL interface
High-precision 1 dB step resolution across the full range
Compact 2.92mm connectorized design for reliable interconnects

Applications

RF test and measurement instrumentation
Telecommunications equipment signal conditioning
Automated testing systems requiring variable loss

Procurement Notes

Verify the specific datasheet version to confirm electrical tolerances and pinout configurations. Ensure compatibility with existing TTL control logic levels in your system design. Confirm mechanical dimensions against available mounting space constraints before finalizing procurement decisions.

Selection Notes

Select this model when precise digital control over attenuation is required rather than manual adjustment. The 2.92mm interface offers superior performance at higher frequencies compared to standard N-type connectors. Consider the 1 dB resolution as sufficient for most calibration tasks while balancing cost against finer resolution alternatives.

Part Context

This part belongs to Pasternack's series of programmable attenuators. It serves as a critical component in systems needing dynamic signal level management. The 2.92mm form factor distinguishes it from larger connector-based variants, offering better high-frequency stability.

Replacement Considerations

No direct public substitute part numbers are confirmed for this specific programmable configuration. Manual step attenuators like the PE70A1048N offer similar frequency ranges but lack programmability. Verify interface compatibility if substituting with other 2.92mm components.
