PE70A5008

Overview

The PE70A5008 is a rotary step attenuator manufactured by Pasternack, designed for RF applications up to 3 GHz. It features SMA female connectors and provides an attenuation range of 0 to 95 dB with 1 dB resolution steps. The device operates at a 50 Ohm impedance and supports a maximum power rating of 2 Watts. Key electrical specifications include a typical VSWR of 1.4:1 and insertion loss characteristics consistent with its step configuration. It is engineered for cable mount installation and functions within a temperature range of -40°C to +85°C.

Feature Summary

• Provides precise 1 dB step attenuation control via rotary mechanism
• Supports high isolation levels across the operational frequency band
• Features durable SMA female-to-female connector interface

Applications

• RF signal testing and measurement instrumentation
• Telecommunications equipment calibration
• Laboratory signal level adjustment

Procurement Notes

Verify the specific datasheet version for the PE70A5008 to confirm exact mechanical dimensions and connector gender details. Ensure that the required attenuation range and power handling capabilities align with the system design before procurement. Cross-reference the manufacturer's official documentation for any updates regarding compliance or material specifications.

Selection Notes

Select this component when a wide dynamic range of attenuation is required in a compact form factor. The rotary style offers manual adjustment suitable for benchtop setups. Confirm that the SMA interface matches existing cabling infrastructure. Evaluate thermal management requirements given the 2 Watt power rating and operating temperature limits.

Part Context

This part belongs to Pasternack's series of RF variable attenuators. It complements other models in the lineup that offer different attenuation ranges or connector types. The product line focuses on providing reliable signal control solutions for professional RF environments, ensuring consistency in performance across various configurations.

Replacement Considerations

Check for direct substitutes within the same manufacturer series that may offer alternative connector interfaces or extended frequency ranges. Verify compatibility with existing mounting hardware and signal paths when considering alternative part numbers.
