PE70A5013

Overview

The PE70A5013 is a bench-top programmable step attenuator manufactured by Pasternack. It operates within a frequency range of 200 MHz to 6 GHz and features a nominal impedance of 50 Ohms. The device provides an attenuation range from 0 dB to 95 dB with selectable step sizes. It utilizes SMA connectors for interface connections. The unit is designed for TTL-controlled operation, allowing for precise digital adjustment of signal levels in RF test and measurement environments.

Feature Summary

• TTL-controlled programmable operation for automated testing systems
• Wideband frequency coverage from 200 MHz to 6 GHz
• High dynamic attenuation range up to 95 dB
• Bench-top form factor for laboratory integration

Applications

• Automated RF test equipment control
• Signal level calibration in measurement setups
• Microwave component characterization
• R&D laboratory signal generation

Procurement Notes

Verify the specific SMA connector gender and cable assembly requirements before ordering. Confirm that the TTL control voltage levels match your system interface. Ensure the operating frequency range covers your application spectrum. Check for any required accessories or mounting hardware not included in the standard package.

Selection Notes

Select this model when high-precision programmable attenuation is required across the UHF to microwave bands. Consider the physical dimensions and weight for benchtop integration. Evaluate the need for TTL compatibility versus other control interfaces if using different automation hardware. Verify impedance matching for your specific 50 Ohm system architecture.

Part Context

This component belongs to Pasternack's line of bench-top programmable attenuators. These devices are engineered for stability and repeatability in professional test environments. The series supports various attenuation ranges and control methods to suit different RF testing needs. They serve as critical components in signal chain management for advanced electronic testing.

Replacement Considerations

Check for compatible models with similar attenuation ranges and frequency limits. Verify interface compatibility if substituting with different connector types. Ensure control logic matches existing automation infrastructure. Consult manufacturer documentation for direct cross-reference part numbers.
