PE70A9005

Overview

The Pasternack PE70A9005 is a push-button step attenuator featuring N female to N female connectors. It provides an attenuation range of 0 to 90 dB with 1 dB steps. The device operates up to 3 GHz and is rated for 2 Watts power handling. It maintains a VSWR of 1.5:1 maximum and functions within a temperature range of -20°C to +85°C.

Feature Summary

• Push-button mechanical stepping mechanism
• N-type female connector interface
• High precision 1 dB step resolution

Applications

• RF signal level control
• Test and measurement setups
• Calibration equipment integration

Procurement Notes

Verify the specific datasheet revision and RoHS compliance status directly with Pasternack or authorized distributors before procurement. Confirm that the 2-watt power rating aligns with your system's thermal requirements. Ensure connector compatibility matches your existing N-type infrastructure.

Selection Notes

Select this model when precise, high-range attenuation is required in N-type systems. Consider the 3 GHz frequency limit and 2-watt power capacity against your operational needs. Evaluate the physical size and weight constraints compared to rotary alternatives if space is limited.

Part Context

This component belongs to the RF Variable Attenuators series by Pasternack. It falls under the Connectorized Attenuators subcategory, designed for interconnect applications requiring reliable signal reduction in radio frequency environments.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult Pasternack technical support for direct equivalents or cross-reference options based on specific performance criteria.
