PE70A9010

$431.38

Description：Positive Slope Equalizer, 6 GHz
Series：-
Mfr：Pasternack
Package：Retail Package

SKU:57e2a98542cc Category: RF Misc ICs and Modules Brand: Pasternack

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：Positive Slope Equalizer, 6 GHz
Series：-
Mfr：Pasternack
Package：Retail Package
Function：Linear Equalizer
Frequency：6GHz ~ 18GHz
RF Type：General Purpose
Secondary Attributes：SMA Connectors
Mounting Type：Chassis Mount
Package / Case：SMA In-Line Module
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

PE70A9010

Overview

The PE70A9010 is a linear equalizer designed for RF applications, manufactured by Pasternack. It operates within a frequency range of 6 GHz to 18 GHz and utilizes SMA connectors for interface connectivity. The component provides a fixed positive slope equalizing value of 1.4 dB to compensate for signal variations. It exhibits an insertion loss of 1.5 dB during operation. This device is classified as a general-purpose RF type suitable for maintaining signal integrity across the specified microwave frequency band.

Feature Summary

Provides a fixed positive slope equalizing value of 1.4 dB
Operates effectively within the 6 GHz to 18 GHz frequency range
Features SMA connector interfaces for standard integration

Applications

General-purpose RF signal conditioning
Microwave system frequency/gain equalization
Test and measurement instrumentation

Procurement Notes

Verify the specific datasheet documentation for the PE70A9010 to confirm detailed electrical performance characteristics and mechanical dimensions. Ensure that the SMA connector polarity and mating requirements align with the existing system architecture before finalizing procurement decisions.

Selection Notes

Select this component when a fixed positive slope equalization is required between 6 GHz and 18 GHz. Consider the 1.5 dB insertion loss impact on overall system gain budget. Verify compatibility with SMA connector types and ensure the operating environment supports the specified frequency range for optimal performance.

Part Context

This component belongs to the category of RF equalizers produced by Pasternack. It serves as a passive or active network element depending on internal design, aimed at correcting amplitude-frequency response deviations in high-frequency circuits. The product line focuses on providing stable signal characteristics across wide bandwidths using standardized connector interfaces.
