PE70A9018

$512.72

Description：Positive Slope Equalizer, 26.5 G
Series：-
Mfr：Pasternack
Package：Retail Package

SKU:b8a555caf19d Category: RF Misc ICs and Modules Brand: Pasternack

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：Positive Slope Equalizer, 26.5 G
Series：-
Mfr：Pasternack
Package：Retail Package
Function：Linear Equalizer
Frequency：26.5GHz ~ 40GHz
RF Type：General Purpose
Secondary Attributes：SMA Connectors
Mounting Type：Chassis Mount
Package / Case：2.92mm In-Line Module
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

PE70A9018

Overview

The Pasternack PE70A9018 is a positive slope equalizer designed for high-frequency applications ranging from 26.5 GHz to 40 GHz. It provides a fixed equalizing value of 4 dB with a maximum insertion loss of 2.5 dB. The component features a field-replaceable 2.92mm connector interface and supports a maximum input power of +30 dBm. This device compensates for signal attenuation characteristics in RF systems operating within the specified millimeter-wave frequency band.

Feature Summary

Provides fixed positive slope equalization across the 26.5 GHz to 40 GHz range
Features a field-replaceable 2.92mm connector interface for maintenance flexibility
Supports high-power operation with a maximum pin rating of +30 dBm

Applications

Millimeter-wave test and measurement instrumentation
High-frequency communication system calibration
RF signal path compensation in advanced radar systems

Procurement Notes

Verify the specific connector type and physical dimensions against your system requirements before ordering. Confirm that the fixed 4 dB equalization value aligns with your signal processing needs. Ensure the maximum input power rating of +30 dBm is sufficient for your application's peak signal levels. Check for any specific environmental or mounting constraints required by the field-replaceable design.

Selection Notes

Select this component when a fixed positive slope correction is required between 26.5 GHz and 40 GHz. Consider the field-replaceable nature if long-term serviceability is a priority. Evaluate the 2.5 dB insertion loss impact on your overall link budget. Compare against adjustable equalizers if variable gain compensation is needed instead of a fixed value.

Part Context

This part belongs to Pasternack's specialized RF equalizer portfolio, targeting millimeter-wave frequencies. It addresses signal integrity issues caused by frequency-dependent losses in transmission paths. The design focuses on precision equalization rather than amplification, ensuring flat response characteristics in high-speed data links.
