PE70A9030

$1,564.68

Description：Negative Slope Equalizer, 6 GHz
Series：-
Mfr：Pasternack
Package：Retail Package

SKU:c61c5d56efe7 Category: RF Misc ICs and Modules Brand: Pasternack

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：Negative Slope Equalizer, 6 GHz
Series：-
Mfr：Pasternack
Package：Retail Package
Function：Linear Equalizer
Frequency：6GHz ~ 18GHz
RF Type：General Purpose
Secondary Attributes：SMA Connectors
Mounting Type：Chassis Mount
Package / Case：SMA In-Line Module
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

PE70A9030

Overview

The PE70A9030 is a negative slope equalizer manufactured by Pasternack, designed for signal conditioning applications within the 6 GHz to 18 GHz frequency range. This component provides a fixed equalizing value of 3 dB and exhibits an insertion loss of 0.9 dB. It features SMA connectors and supports a maximum input power (Pin) of 150 mW. The device operates as a linear equalizer intended to compensate for signal degradation in high-frequency RF systems.

Feature Summary

Provides fixed negative slope equalization to correct frequency response variations
Operates across a wide bandwidth from 6 GHz to 18 GHz
Features low insertion loss characteristics for efficient signal transmission

Applications

Signal conditioning in microwave communication links
Compensation for cable and connector frequency-dependent losses
Test and measurement equipment requiring flat frequency response

Procurement Notes

Verify that the required operating frequency aligns with the 6 GHz to 18 GHz specification. Confirm that the system's maximum input power does not exceed the 150 mW rating to prevent component damage. Ensure SMA connector compatibility with existing circuit interfaces. Review the official datasheet for precise impedance and VSWR parameters before integration.

Selection Notes

Select this model when a fixed negative slope correction is required rather than variable attenuation. The 3 dB equalizing value is specific to compensating for particular channel losses. Consider the 0.9 dB insertion loss impact on overall system gain. Verify that the SMA interface matches the design requirements without additional adapters.

Part Context

This component belongs to the RF IC Linear Equalizer category within Pasternack's portfolio. It serves as a passive signal conditioning element distinct from active amplifiers or variable attenuators. The fixed nature of the 3 dB equalization makes it suitable for static compensation scenarios in high-frequency RF architectures.
