PE7206-30

Overview

The Pasternack PE7206-30 is a fixed RF attenuator designed for in-line signal reduction. It provides a nominal attenuation of 30 dB within a frequency range extending up to 18 GHz. The component utilizes a resistive PI pad topology and maintains a system impedance of 50 Ohms. It features N female connectors on both input and output ports, facilitating integration into coaxial cable assemblies. The device is constructed as an inline unit suitable for high-power applications.

Feature Summary

• Fixed 30 dB attenuation value
• N female connector interface
• Resistive PI pad design
• Inline coaxial form factor

Applications

• RF signal level adjustment
• Test and measurement setups
• Communication systems
• Aerospace and defense electronics

Procurement Notes

Verify the specific datasheet version for the PE7206-30 to confirm exact power handling ratings and frequency limits. Ensure connector compatibility with existing N-type interfaces. Check for any environmental specifications if operating in extreme conditions. Confirm that the 50 Ohm impedance matches the system requirements. Review manufacturer documentation for proper installation torque values.

Selection Notes

Select this model when a precise 30 dB reduction is required at frequencies up to 18 GHz. The N female interface dictates mating connector types. Consider the physical size and power rating relative to the application environment. Compare with other Pasternack models like PE7206-20 or PE7206-40 if different attenuation levels are needed. Ensure the inline design fits the available space in the assembly.

Part Context

This component belongs to the Pasternack PE7206 series of fixed attenuators. The series offers various attenuation values while maintaining consistent connector types and impedance. These devices are engineered for reliability in demanding RF environments. The PE7206-30 specifically addresses the need for significant signal reduction without introducing excessive reflection.

Replacement Considerations

Direct substitutes include other Pasternack models with identical N female connectors and 30 dB attenuation, such as those from the PE7206 series. Verify that replacement units match the 50 Ohm impedance and frequency range. Cross-reference with industry-standard N-type fixed attenuators if brand flexibility is permitted.
