PE7221-6

Overview

The PE7221-6 is a fixed attenuator manufactured by Pasternack Enterprises. It provides an attenuation value of 6 dB and operates with SMA connectors, specifically featuring a female-to-male configuration. The component is rated for power handling up to 50 watts and supports frequency ranges extending up to 18 GHz. This device is designed for use in radio frequency applications requiring precise signal reduction within the specified bandwidth.

Feature Summary

• Provides a fixed attenuation level of 6 dB for signal management
• Utilizes SMA connector interface with female-to-male orientation
• Rated for continuous power handling up to 50 watts
• Operates effectively within frequency ranges up to 18 GHz

Applications

• Radio frequency signal conditioning
• Test and measurement equipment interconnects
• Communication system signal level adjustment

Procurement Notes

Verify the specific datasheet version for the PE7221-6 to confirm exact electrical tolerances and mechanical dimensions. Ensure compatibility with existing SMA interfaces regarding gender and mating cycles. Confirm that the 50-watt power rating aligns with operational requirements to prevent damage. Check for RoHS compliance status if environmental regulations apply to the deployment environment.

Selection Notes

Select this component when a fixed 6 dB reduction is required in an RF path operating below 18 GHz. The SMA interface suits standard laboratory and industrial setups. Consider the 50-watt power limit when designing systems with high-power sources. Verify connector gender requirements to ensure correct male-to-female connectivity in the assembly.

Part Context

This part belongs to the Pasternack fixed attenuator series, which offers various attenuation values and connector types. The PE7221-6 specifically addresses needs for moderate signal reduction using widely available SMA connections. It serves as a passive component for maintaining signal integrity in high-frequency circuits without active amplification or complex tuning mechanisms.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Users should consult manufacturer catalogs for equivalent SMA fixed attenuators with matching 6 dB attenuation and 50-watt ratings.
