PE7312-6

Overview

The Pasternack PE7312-6 is a fixed 6 dB attenuator designed for coaxial RF applications. It features 7/16 DIN male connectors on both ends, providing an inline connection interface. The component operates at a characteristic impedance of 50 Ohms and utilizes a resistive PI attenuator pad design for signal attenuation. This configuration ensures consistent performance within its specified frequency range, suitable for precision signal level management in RF systems.

Feature Summary

• Resistive PI attenuator pad design for stable signal reduction
• Inline coaxial construction with 7/16 DIN male connectors
• 50 Ohm characteristic impedance for standard RF system integration

Applications

• RF signal level adjustment in communication systems
• Test and measurement equipment signal conditioning
• Preventing receiver overload in high-power RF chains

Procurement Notes

Verify the specific datasheet for the PE7312-6 to confirm the exact operating frequency range and power handling capabilities. Ensure that the 7/16 DIN connector compatibility matches the existing system infrastructure. Check for any environmental ratings or mounting requirements if the application involves harsh conditions.

Selection Notes

Select this component when a precise 6 dB attenuation is required in a 50 Ohm system using 7/16 DIN interfaces. Consider the power rating and frequency limits defined in the official documentation to ensure the attenuator can handle the expected signal levels without degradation or damage.

Part Context

This part belongs to Pasternack's line of fixed attenuators, which are passive components used to reduce signal amplitude. The PE7312-6 specifically addresses applications requiring robust 7/16 DIN connectivity, a common standard in base station and industrial RF environments where secure connections are critical.
