PE7315-6

Overview

The Pasternack PE7315-6 is a fixed attenuator module designed for RF and microwave applications. It provides a precise attenuation value of 6 dB across a frequency range from DC to 7.5 GHz. The component features an N female input connector and a 7/16 DIN female output connector, facilitating integration into systems requiring mixed interface standards. Rated for 50 Watts of power at the specified attenuation level, it supports robust signal management in high-power environments.

Feature Summary

• Provides fixed 6 dB attenuation for signal level control
• Operates effectively from DC up to 7.5 GHz frequency range
• Supports 50 Watts power handling capacity at rated attenuation
• Features N female to 7/16 DIN female interface configuration

Applications

• RF test and measurement equipment signal conditioning
• Microwave communication system power reduction
• Antenna feed line attenuation for impedance matching
• Laboratory instrumentation signal scaling

Procurement Notes

Verify that the specific application environment does not exceed the 50 Watt power rating or 7.5 GHz frequency limit. Confirm compatibility between N female and 7/16 DIN connectors with existing system hardware. Ensure proper torque specifications are applied during installation to maintain performance integrity and prevent mechanical damage to the interfaces.

Selection Notes

Select this model when a fixed 6 dB reduction is required within the 7.5 GHz bandwidth. Consider the mixed connector types (N and 7/16 DIN) as a key selection factor for interfacing different subsystems. Evaluate the 50 Watt power handling against peak signal levels to ensure reliable operation without thermal degradation or performance loss in the intended circuit design.

Part Context

This component belongs to Pasternack's attenuator product line, which includes various fixed and variable attenuation solutions for RF and microwave frequencies. These modules are engineered to provide stable, precise attenuation values essential for maintaining signal integrity in complex electronic systems and measurement setups.

Replacement Considerations

No public confirmed substitute part numbers are available for direct replacement.
