PE7316-30

Overview

The Pasternack PE7316-30 is a fixed RF attenuator module designed for high-power applications. It provides a precise attenuation value of 30 dB across a frequency range of 0 Hz to 7.5 GHz. The component operates with a characteristic impedance of 50 Ohms and features N-type connectors on both the input and output ports. This model is engineered to handle significant power levels, ensuring stable performance in demanding radio frequency environments.

Feature Summary

• Provides fixed 30 dB attenuation for signal level control
• Operates within a wide frequency bandwidth up to 7.5 GHz
• Constructed with robust N-type connector interfaces
• Designed for high-power handling capabilities

Applications

• RF test and measurement setups requiring precise signal reduction
• High-power transmitter line monitoring and protection
• Antenna system calibration and testing
• Radio frequency circuit development and validation

Procurement Notes

Verify the specific datasheet version for the PE7316-30 to confirm exact power ratings and connector specifications. Ensure compatibility with existing N-type interfaces in your assembly. Cross-reference official Pasternack documentation for thermal management requirements and maximum operating frequencies before integration into final designs.

Selection Notes

Select this model when a fixed 30 dB reduction is required at frequencies extending to 7.5 GHz. Consider the 50 Ohm impedance match for standard RF systems. Evaluate the power handling capacity against peak signal levels to prevent damage. Compare with adjustable attenuators if variable control is needed instead of a fixed value.

Part Context

This component belongs to Pasternack's series of fixed RF attenuators. These modules are typically used to reduce signal amplitude without introducing significant distortion. The PE7316-30 variant specifically targets applications needing reliable attenuation in broadband scenarios using standard N-type connections.

Replacement Considerations

Check for direct substitutes with identical 30 dB attenuation and N-type interfaces. Verify that alternative models support the same 7.5 GHz upper frequency limit and power handling specifications. Ensure mechanical dimensions and connector gender match the existing setup.
