PE7363-30

Overview

The Pasternack PE7363-30 is a fixed 30 dB RF attenuator designed for in-line applications. It features SMA female-to-female connectors and operates within a frequency range of DC to 18 GHz. The component utilizes a resistive PI attenuator pad design to ensure stable performance. It is rated for 50 Ohms impedance and can handle up to 25 Watts of power at the stated attenuation value. This coaxial module is suitable for precision measurements and production systems requiring reliable signal reduction.

Feature Summary

• In-line resistive PI attenuator pad design for consistent signal attenuation
• SMA female-to-female connector configuration for easy integration
• Rated for 25 Watts power handling up to 18 GHz frequency range

Applications

• Precision measurement systems
• Production test environments
• RF signal level adjustment

Procurement Notes

Verify the specific datasheet version and manufacturer documentation to confirm electrical parameters such as VSWR and insertion loss. Ensure compatibility with system impedance and power requirements before procurement. Cross-reference part numbers with official Pasternack catalogs to avoid counterfeit components or incorrect specifications.

Selection Notes

Select this model when a fixed 30 dB attenuation is required between DC and 18 GHz. The SMA female interface suits applications needing direct connection without adapters. Consider the 25 Watt power rating for high-power RF paths. Verify that the physical size and mounting style meet the enclosure constraints of the target assembly.

Part Context

This component belongs to Pasternack's series of fixed coaxial attenuators. It provides a standardized solution for reducing RF signal strength in microwave circuits. The product line typically includes various attenuation values and connector types to support diverse RF testing and communication infrastructure needs.

Replacement Considerations

Compatible substitutes include other 30 dB fixed attenuators with SMA female connectors and similar frequency ratings. Ensure replacement parts match the 50 Ohm impedance and power handling capabilities. Verify mechanical dimensions and connector gender to maintain system integrity.
