PE7367-10

Overview

The Pasternack PE7367-10 is a fixed RF attenuator designed for coaxial applications. It provides an attenuation value of 10 dB across a frequency range from 0 Hz to 18 GHz. The device features Type N male connectors on both input and output sides, ensuring compatibility with standard Type N interfaces. It operates at a maximum power rating of 25 watts and maintains a characteristic impedance of 50 Ohms. The housing is constructed with black anodized aluminum for durability.

Feature Summary

• Provides consistent 10 dB signal attenuation
• Operates up to 18 GHz frequency range
• Features Type N male-to-male connector configuration
• Rated for 25 watts maximum power handling

Applications

• RF test and measurement setups
• Signal level reduction in communication systems
• Impedance matching in 50 Ohm networks
• Laboratory equipment calibration

Procurement Notes

Verify the specific connector gender configuration matches system requirements. Confirm that the 25-watt power rating aligns with operational limits. Ensure the 18 GHz frequency coverage meets application needs. Check for any environmental specifications regarding the black anodized finish if used in harsh conditions.

Selection Notes

Select this component when a precise 10 dB reduction is required within the 0-18 GHz spectrum. Consider the Type N interface compatibility with existing cabling infrastructure. Evaluate the 25-watt power capacity against peak signal levels. Compare with other attenuators if different impedance or connector types are necessary.

Part Context

This model belongs to the Pasternack series of fixed attenuators. It serves as a passive component for managing signal strength in high-frequency circuits. The design focuses on reliability and performance within the UHF and microwave bands.

Replacement Considerations

Substitutes must match the 10 dB attenuation value, 50 Ohm impedance, and Type N male connectors. Verify that alternative models support the 18 GHz frequency range and 25-watt power rating. Ensure physical dimensions allow for equivalent installation space.
