PE7367-40

Overview

The Pasternack PE7367-40 is a fixed RF attenuator module designed for high-frequency signal management. It provides a precise attenuation value of 40 dB across a frequency range extending from 0 Hz to 18 GHz. The component features Type N connectors with male gender on both input and output sides, ensuring compatibility with standard coaxial systems. It operates at a characteristic impedance of 50 Ohms and supports a maximum power handling capacity of 25 Watts. This inline module is constructed for reliable performance in demanding radio frequency environments.

Feature Summary

• Provides stable 40 dB signal reduction across a wide bandwidth up to 18 GHz
• Features robust Type N male-to-male connector interface for secure inline integration
• Supports high power handling capability of 25 Watts for transmitter applications

Applications

• Radio frequency test and measurement setups requiring precise signal level control
• Transmitter output stages for power reduction and system protection
• Receiver input stages to prevent overload and improve dynamic range

Procurement Notes

Verify the specific datasheet version and manufacturing lot details upon order confirmation. Ensure that the procurement documentation explicitly confirms the 40 dB attenuation tolerance and the 18 GHz upper frequency limit. Confirm that the Type N connector gender matches the required male-to-male configuration for your specific cable assembly or panel mount application.

Selection Notes

Select this component when a fixed 40 dB attenuation is required within an 18 GHz operational bandwidth. The 50 Ohm impedance rating must align with the surrounding transmission line infrastructure. Consider the 25 Watt power rating to ensure safe operation under expected load conditions. The Type N connector type dictates the mating hardware requirements for installation.

Part Context

This model belongs to the Pasternack series of fixed coaxial attenuators. These components are engineered to provide consistent signal loss without introducing significant reflection or phase shift. The design focuses on maintaining impedance continuity while reducing signal amplitude, serving as a fundamental passive element in RF circuit design and signal conditioning chains.

Replacement Considerations

PE7002-40 serves as a parametric equivalent alternative offering similar attenuation characteristics.
