Product Detailed Parameters
- Description：High Power Limiter, SMA, 100W Pe
- Series：-
- Mfr：Pasternack
- Package：Retail Package
- Function：Limiter
- Frequency：500MHz ~ 2GHz
- RF Type：General Purpose
- Secondary Attributes：100W
- Mounting Type：Chassis Mount
- Package / Case：SMA In-Line Module
- Supplier Device Package：-
- Grade：-
- Qualification：-
Download product information
Overview
The PE8018 is a high power limiter manufactured by Pasternack, designed for signal conditioning in RF applications. It features SMA connectors and operates within a frequency range of 500 MHz to 2 GHz. The device handles a peak power of 100 Watts with a recovery time of 20 ns. It maintains a flat leakage of 19 dBm. This component serves as a protective element for sensitive downstream equipment against high power transients.
Feature Summary
- Provides signal conditioning through high power limiting capabilities
- Utilizes SMA connector interface for standard integration
- Ensures protection against power transients with specified recovery speed
Applications
- RF system protection for sensitive components
- Signal conditioning in wireless communication infrastructure
- Test and measurement equipment input stages
Procurement Notes
Verify the specific datasheet version and RoHS compliance status before procurement. Confirm that the SMA connector type matches the system requirements. Ensure the operating frequency range aligns with the application needs. Check for any specific handling instructions regarding high power thresholds.
Selection Notes
Select this component when high power protection is required within the 500 MHz to 2 GHz band. Consider the 100W peak power rating and 20 ns recovery time for transient events. Evaluate the 19 dBm leakage level for signal integrity constraints. Ensure compatibility with existing SMA interfaces in the design.
Part Context
The PE8018 belongs to Pasternack's lineup of signal conditioning devices. It functions as a passive limiter to safeguard active components from damage due to excessive input power. The device is distinct from attenuators or amplifiers, focusing solely on power clamping and protection within its specified frequency range.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing SMA-based designs if considering alternatives. Ensure replacement parts meet the same 100W peak power and frequency specifications.
