PE8029

$654.16

Description：High Power Limiter, SMA, 200W Pe
Series：-
Mfr：Pasternack
Package：Retail Package

SKU:97a44b798f07 Category: RF Misc ICs and Modules Brand: Pasternack

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：High Power Limiter, SMA, 200W Pe
Series：-
Mfr：Pasternack
Package：Retail Package
Function：Limiter
Frequency：500MHz ~ 2GHz
RF Type：General Purpose
Secondary Attributes：-
Mounting Type：Chassis Mount
Package / Case：SMA In-Line Module
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

PE8029

Overview

The PE8029 is a general-purpose RF limiter manufactured by Pasternack. It operates within a frequency range of 500 MHz to 2 GHz and utilizes SMA connectors. The device handles a peak power of 200 Watts with a recovery time of 200 microseconds. Key electrical specifications include a maximum insertion loss of 0.6 dB, a flat leakage of 14 dBm (0.02 W), and an input power rating of 30 dBm. It functions using PIN-Schottky technology.

Feature Summary

Provides protection for sensitive downstream components against high-power RF signals
Utilizes PIN-Schottky technology for effective signal limiting
Maintains low insertion loss during normal operation

Applications

General-purpose RF circuit protection
Receiver front-end protection in communication systems
Test and measurement equipment safeguarding

Procurement Notes

Verify the specific datasheet version when ordering, as manufacturing details may evolve. Confirm that the SMA connector interface matches your system requirements. Ensure the operating environment stays within the specified temperature limits. Check for any RoHS compliance documentation if required by your procurement policy. Validate the peak power handling capability against your system's maximum expected surge levels.

Selection Notes

Select this component when a general-purpose limiter is needed for frequencies between 500 MHz and 2 GHz. Consider the 200W peak power rating to ensure adequate protection margins. The SMA interface suits standard coaxial setups. Evaluate the 0.6 dB insertion loss impact on system sensitivity. Verify compatibility with the 14 dBm leakage level for your specific application constraints.

Part Context

This part belongs to Pasternack's portfolio of RF misc ICs and modules, specifically categorized under limiters. It serves as a protective element in radio frequency paths. The product line focuses on providing reliable signal management solutions for various electronic applications.
