PE82P2002

Overview

The PE82P2002 is an analog phase shifter manufactured by Pasternack, designed for operation within the 8 GHz to 18 GHz frequency range. It provides a continuous 360-degree phase shift capability with a control voltage input spanning from 0V to +13V. The component supports a maximum input power of +26 dBm and utilizes SMA connectors for RF interfacing. This device is categorized under wireless and RF integrated circuits, specifically functioning as a phase detector or shifter.

Feature Summary

• Provides continuous 360-degree phase adjustment across the specified microwave frequency band
• Operates using a linear analog control voltage interface ranging from 0V to +13V
• Engineered to withstand high RF input power levels up to +26 dBm

Applications

• Phased array antenna beam steering systems
• Microwave test and measurement instrumentation
• Radio frequency signal processing circuits

Procurement Notes

Verify the specific SMA connector gender and cable assembly requirements for your system integration. Confirm that the control voltage supply matches the 0V to +13V specification. Ensure the operating environment remains within the 8 GHz to 18 GHz operational bandwidth. Check for any thermal management needs associated with the +26 dBm power handling capability.

Selection Notes

Select this component when a fully analog phase control solution is required for frequencies between 8 GHz and 18 GHz. It is suitable for applications demanding precise phase alignment without digital quantization steps. Consider the physical size and weight constraints, as it is packaged in bulk. Evaluate if the analog control interface aligns with your existing driver circuitry capabilities.

Part Context

This part belongs to Pasternack's portfolio of wireless and RF integrated circuits. It falls under the category of phase detectors and shifters, distinct from their digital programmable series. The product is classified as a new item from the manufacturer, indicating recent availability in their catalog lineup.

Replacement Considerations

No public substitute part numbers are documented. Compare against other Pasternack analog phase shifters if different frequency ranges or control voltages are needed.
