PE82P2009

Overview

The PE82P2009 is a general-purpose RF IC phase shifter manufactured by Pasternack. It operates within the frequency range of 22 GHz to 33 GHz. The device provides a total phase shift capability of 360 degrees, allowing for comprehensive signal phase adjustment across its operational bandwidth.

Feature Summary

• Provides continuous 360-degree phase shift capability
• Operates in the high-frequency microwave spectrum from 22 GHz to 33 GHz
• Designed as a general-purpose integrated circuit component

Applications

• Microwave communication systems
• Radar signal processing
• Test and measurement equipment

Procurement Notes

Verify the specific datasheet version for precise insertion loss and VSWR specifications before integration. Confirm that the operating environment remains within the 22 GHz to 33 GHz range to ensure optimal performance. Ensure proper impedance matching is implemented during PCB layout to maintain signal integrity at these high frequencies.

Selection Notes

Select this component when a full 360-degree phase rotation is required in the K-band or higher microwave frequencies. It serves as a suitable solution for applications needing broad phase coverage without switching between discrete states. Consider thermal management requirements associated with RF IC operation in dense assemblies.

Part Context

This part belongs to Pasternack's portfolio of RF integrated circuits and modules designed for specialized microwave applications. It complements other phase shifters in their lineup that cover lower frequency bands, offering engineers a standardized interface for high-frequency phase control tasks.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Engineers should consult the manufacturer directly for cross-reference information or equivalent components meeting identical 22-33 GHz specifications.
