PE82P5004

$1,096.50

Description：PHASE SHIFTER: SMA F 0-2GHZ
Series：-
Mfr：Pasternack
Package：Case

SKU:0a8238a87641 Category: RF Misc ICs and Modules Brand: Pasternack

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：PHASE SHIFTER: SMA F 0-2GHZ
Series：-
Mfr：Pasternack
Package：Case
Function：Phase Shifter, Trimmer
Frequency：0Hz ~ 2GHz
RF Type：Radar
Secondary Attributes：60° Phase Shift
Mounting Type：Chassis Mount
Package / Case：Module
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

PE82P5004

Overview

The PE82P5004 is an adjustable phase shifter manufactured by Pasternack, designed for RF and wireless applications. It operates within a frequency range of DC to 2GHz. The device features SMA connectors and provides an adjustable phase shift capability of 60 degrees per GHz. This component is classified under phase detectors and shifters, serving as a critical element in radar and signal processing systems where precise phase control is required across the specified bandwidth.

Feature Summary

Provides continuous adjustable phase shifting functionality
Operates from DC up to 2GHz frequency range
Equipped with SMA interface connectors

Applications

Radar system phase control
Wireless communication signal processing
RF test and measurement equipment

Procurement Notes

Verify the specific SMA connector gender and pin configuration against your schematic requirements before integration. Confirm RoHS compliance status through the official datasheet or manufacturer documentation. Ensure the operating environment remains within the specified DC to 2GHz range to maintain performance integrity. Check for any regional shipping restrictions that may apply to this component.

Selection Notes

Select this component when a fixed phase shift is insufficient and dynamic adjustment between 0 and 120 degrees is needed. The 60 degrees per GHz specification allows for linear phase tuning relative to frequency. Consider the SMA interface compatibility with existing PCB traces or cable assemblies. Evaluate thermal management needs if operating at high power levels within the 2GHz limit.

Part Context

This part belongs to Pasternack's adjustable phase shifter series, which focuses on providing tunable phase characteristics for RF circuits. Unlike fixed delay lines, these components allow for real-time phase alignment adjustments. The series typically utilizes standard SMA interfaces for ease of integration into modular RF systems and test setups requiring flexible phase manipulation capabilities.
