PE82P5007

$1,275.00

Description：PHASE SHIFTER: SMA F 0-2GHZ
Series：-
Mfr：Pasternack
Package：Case

SKU:a1deade12124 Category: RF Misc ICs and Modules Brand: Pasternack

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：PHASE SHIFTER: SMA F 0-2GHZ
Series：-
Mfr：Pasternack
Package：Case
Function：Phase Shifter, Trimmer
Frequency：0Hz ~ 2GHz
RF Type：Radar
Secondary Attributes：90° Phase Shift
Mounting Type：Chassis Mount
Package / Case：Module
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

PE82P5007

Overview

The Pasternack PE82P5007 is an adjustable phase shifter designed for RF applications. It operates within a frequency range of DC to 2GHz. The device provides a phase adjustment capability of 90 degrees per GHz. It utilizes SMA connectors for signal interfacing. The unit features a precision rotary dial design to allow for controllable phase settings. This component is categorized under wireless and RF integrated circuits, specifically as a phase detector or shifter.

Feature Summary

Adjustable phase shifting with a rate of 90 degrees per GHz across the operational bandwidth
Precision rotary dial mechanism for manual and controllable phase adjustments
SMA connector interface for standard RF integration

Applications

Radar systems requiring precise phase alignment
RF test and measurement equipment needing phase trimming
Wireless communication infrastructure components

Procurement Notes

Verify RoHS compliance status through official manufacturer documentation before procurement. Confirm that the SMA connector type matches system requirements. Check current product availability as distribution may vary by region. Ensure the operating frequency range up to 2GHz aligns with specific application needs. Review datasheet specifications for mechanical dimensions and mounting constraints.

Selection Notes

Select this component when a fixed phase shift is insufficient and adjustable tuning is required. The 90 degrees per GHz adjustment rate offers flexibility for varying frequencies within the 2GHz limit. Consider the SMA interface compatibility with existing cabling and fixtures. Evaluate the need for manual adjustment via the rotary dial against automated control requirements.

Part Context

This part belongs to the Adjustable Phase Shifters series from Pasternack. It serves as a specialized RF component distinct from standard cables or adapters. The function focuses on phase manipulation rather than signal transmission or impedance matching alone. It complements other RF modules in complex signal processing chains.
