PE82P5014

Overview

The Pasternack PE82P5014 is an adjustable phase shifter designed for radio frequency applications. It operates within a frequency range of DC to 2 GHz. The device provides an adjustable phase shift capability defined as 90 degrees per GHz. It utilizes N-type connectors for signal interfacing. The unit features a precision rotary dial for manual phase adjustment. This component belongs to the Adjustable Phase Shifters series and is categorized under Phase Detectors / Shifters.

Feature Summary

• Provides continuous phase adjustment via a precision rotary dial mechanism
• Operates across a wide frequency spectrum from DC up to 2 GHz
• Features N-type connectors for standard RF interface compatibility

Applications

• RF cable phase matching between two cables
• Adjustable phase trimming in RF applications
• Signal path phase alignment in test setups

Procurement Notes

Verify the specific connector type and frequency range requirements against the official datasheet before ordering. Confirm that the N-type interface matches your system infrastructure. Check for any RoHS compliance details if environmental regulations apply to your deployment. Ensure the mechanical dimensions fit your available space constraints.

Selection Notes

Select this model when manual, continuous phase adjustment is required rather than digital steps. It is suitable for low-frequency RF environments up to 2 GHz. Consider the physical size and weight if mounting space is limited. Evaluate the need for a rotary dial versus programmable control for your specific application workflow.

Part Context

This component is part of Pasternack's Adjustable Phase Shifters series. It falls under the broader category of Wireless & RF Integrated Circuits, specifically Phase Detectors / Shifters. The product is identified by the manufacturer number PE82P5014 and is packaged in bulk quantities.
