PE85N1008

Overview

The PE85N1008 is a precision calibrated noise source module manufactured by Pasternack. It utilizes a 2.92mm connector interface and operates within a frequency range of 10 MHz to 6 GHz. The device provides an excess noise ratio (ENR) output of 10 dB and requires a +28 VDC power supply for operation. This component is designed to meet precise radio frequency component standards, ensuring reliable performance in test and measurement applications.

Feature Summary

• Precision calibrated RF noise source generator
• Utilizes 2.92mm connector interface
• Operates with +28 VDC power supply

Applications

• RF system testing
• Noise figure measurements
• Receiver sensitivity analysis

Procurement Notes

Verify the specific datasheet version and calibration certificate details prior to procurement. Confirm that the +28 VDC power requirement aligns with the target test equipment capabilities. Ensure the 2.92mm connector type matches the existing signal chain infrastructure to maintain impedance continuity and signal integrity during deployment.

Selection Notes

Select this model when a 10 dB ENR output is required for accurate noise characterization. The 2.92mm interface supports high-frequency operations up to 6 GHz, making it suitable for advanced RF testing scenarios. Consider the +28 VDC power constraint when designing the test setup power distribution network.

Part Context

This component belongs to the calibrated RF noise source generators series from Pasternack. It serves as a specialized tool for characterizing the noise performance of radio frequency systems. The module integrates precision engineering to deliver consistent noise outputs across its specified frequency band.

Replacement Considerations

No public confirmed substitute part numbers are available.
