PE8741

Overview

The Pasternack PE8741 is an eight-section bandpass RF filter module designed for signal conditioning applications. It features SMA female connectors and operates within a frequency range of 7.25 GHz to 7.75 GHz, providing a 500 MHz passband centered at 7.5 GHz. The unit exhibits a typical insertion loss of 1.75 dB. This component is engineered for high-frequency signal filtering in radio frequency systems requiring precise spectral selection.

Feature Summary

• Eight-section bandpass filter design for enhanced signal selectivity
• SMA female connector interface for standard integration
• Optimized for operation between 7.25 GHz and 7.75 GHz

Applications

• Radio frequency signal conditioning
• Spectral filtering in communication systems
• Test and measurement equipment

Procurement Notes

Verify the specific datasheet version when sourcing this component to ensure compatibility with your system requirements. Confirm that the SMA female connectors match your existing infrastructure. Check for any updated compliance certifications or manufacturing revisions before finalizing procurement decisions.

Selection Notes

Select the PE8741 when an eight-section bandpass response is required around the 7.5 GHz center frequency. Ensure the 500 MHz bandwidth aligns with your signal processing needs. Verify that the SMA interface is suitable for your board layout and interconnection strategy.

Part Context

This component belongs to Pasternack's line of RF filters, specifically designed for signal conditioning tasks. It serves as a specialized module for managing frequency spectra in high-frequency electronic environments, distinct from general-purpose passive components.

Replacement Considerations

No public confirmed substitute part numbers are available for this specific model.
