Product Detailed Parameters
- Description：RF FILTER LOW PASS 5.5GHZ MODULE
- Series：-
- Mfr：Pasternack
- Package：Retail Package
- Frequency：5.5GHz Center
- Bandwidth：11GHz
- Filter Type：Low Pass
- Ripple：-
- Insertion Loss：1.5dB
- Mounting Type：Chassis Mount
- Package / Case：Module, SMA Connectors
- Size / Dimension：1.201" L x 0.551" W (30.50mm x 14.00mm)
- Height (Max)：0.451" (11.45mm)
Download product information
Overview
The Pasternack PE87FL1017 is an 11-section lowpass filter designed for RF applications. It operates from DC to 11 GHz with a passband of 11 GHz and features SMA female connectors. The module exhibits a loss of 1.5 dB and has a center frequency of 5.5 GHz. This signal conditioning component is part of the RF coaxial filters series, providing reliable performance in microwave and millimeter-wave environments.
Feature Summary
- Utilizes an 11-section architecture for enhanced filtering characteristics
- Equipped with SMA female connectors for standard interface compatibility
- Designed as a dedicated lowpass filter for RF signal conditioning
Applications
- RF signal conditioning systems
- Microwave circuit integration
- Millimeter-wave equipment testing
Procurement Notes
Verify the specific datasheet version for precise electrical tolerances before integration. Confirm connector gender and mating requirements with existing system interfaces. Ensure environmental ratings align with operational conditions. Cross-reference manufacturer documentation for any recent design changes or obsolescence notices prior to final procurement decisions.
Selection Notes
Select this component when an 11-section lowpass response is required up to 11 GHz. The SMA interface suits standard laboratory and production test setups. Consider the 1.5 dB insertion loss impact on system gain budgets. Evaluate physical bulk packaging constraints against assembly line handling capabilities.
Part Context
This model belongs to Pasternack's extensive line of RF coaxial filters. It serves as a specialized signal conditioning element within broader microwave and radio frequency product portfolios. The component supports various high-frequency testing and communication infrastructure needs requiring precise spectral control.
Replacement Considerations
PE87FL1015 offers a similar 11-section lowpass design but operates up to 7 GHz. Verify if the lower bandwidth meets application requirements. Both models share the SMA female connector interface, simplifying mechanical substitution without adapter usage.
