PE88X2014

Overview

The PE88X2014 is a coaxial frequency multiplier manufactured by Pasternack. It operates as an active frequency doubler with SMA connectors and a 50 Ohm impedance. The device functions within an input frequency range of 4 GHz to 8 GHz, producing an output frequency range of 8 GHz to 16 GHz. This component provides signal conversion for microwave applications requiring precise frequency doubling.

Feature Summary

• Active frequency multiplication functionality
• SMA connector interface configuration
• 50 Ohm system impedance design

Applications

• Microwave signal generation systems
• Frequency synthesis circuits
• Test and measurement instrumentation

Procurement Notes

Verify the specific datasheet version for the PE88X2014 to confirm exact electrical tolerances and pinout configurations. Ensure compatibility with existing SMA infrastructure and 50 Ohm system requirements before integration into final designs.

Selection Notes

Select this model when a compact solution for doubling frequencies between 4 GHz and 8 GHz is required. Consider the SMA interface type and 50 Ohm impedance match against system specifications. Evaluate thermal management needs based on expected power levels in the target application environment.

Part Context

This component belongs to Pasternack's line of RF coaxial frequency multipliers. These devices are designed to provide reliable frequency conversion in microwave and millimeter-wave systems. The product series supports various frequency ranges and connector types to meet diverse engineering requirements.

Replacement Considerations

No public confirmed substitute part numbers are available for the PE88X2014.
