Product Detailed Parameters
- Description：Active 3x Frequency Multiplier,
- Series：-
- Mfr：Pasternack
- Package：Retail Package
- Function：Frequency Multiplier
- Frequency：320MHz ~ 450MHz, 960MHz ~ 1.35GHz
- RF Type：General Purpose
- Secondary Attributes：SMA Connectors
- Mounting Type：Chassis Mount
- Package / Case：Module, SMA Connectors
- Supplier Device Package：-
- Grade：-
- Qualification：-
Download product information
Overview
The PE88X2016 is an active coaxial frequency multiplier manufactured by Pasternack, designed for signal conditioning applications. It operates with SMA connectors and features a 50 Ohm impedance system. The device functions as a 3x frequency multiplier, providing an output frequency range of 960 MHz to 1350 MHz. Key electrical specifications include a conversion gain of 6 dB. This component is engineered to handle specific RF signal processing tasks within defined frequency bands.
Feature Summary
- Active frequency multiplication functionality
- SMA connector interface configuration
- 50 Ohm impedance design
Applications
- RF signal generation systems
- Frequency synthesis circuits
- Telecommunications equipment
Procurement Notes
Verify the exact datasheet version and manufacturer specifications before integration. Confirm that the SMA connector type and 50 Ohm impedance align with your system requirements. Ensure the input frequency range supports the required 3x multiplication to achieve the 960 MHz to 1350 MHz output spectrum. Check for any specific thermal or power supply constraints associated with active multiplier modules.
Selection Notes
Select this component when a compact active solution for tripling RF frequencies is required. The SMA interface simplifies integration into standard test and measurement setups. Consider the 6 dB conversion gain relative to system loss budgets. Verify compatibility with the desired input drive levels to ensure optimal performance within the specified output frequency band.
Part Context
This part belongs to Pasternack's line of active signal conditioning components. It serves as a specialized module for generating higher harmonic frequencies from lower input signals. The use of SMA connectors ensures broad compatibility with common RF infrastructure. It is distinct from passive multipliers by utilizing active circuitry for gain.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Evaluate other Pasternack active multipliers or custom solutions if direct replacement is necessary.
