PE88X2017

Overview

The PE88X2017 is an active frequency multiplier module manufactured by Pasternack. It operates within the MHV connector series and features SMA connectors for interface. The device functions as a 3x frequency multiplier, providing an output frequency range of 1350 MHz to 1800 MHz. It delivers a conversion gain of 9 dB. The unit is packaged in a module format with SMA connectors.

Feature Summary

• Active signal conditioning functionality utilizing a triple frequency multiplication architecture
• Integrated SMA connector interfaces for direct RF interconnection
• Designed for high-frequency signal generation within specified microwave bands

Applications

• Microwave signal generation systems
• Frequency synthesis applications
• RF test and measurement equipment

Procurement Notes

Verify the specific datasheet version for detailed electrical characteristics and mechanical drawings. Confirm that the SMA connector orientation and pinout match your system requirements. Ensure environmental conditions align with the manufacturer's operational specifications for reliable performance.

Selection Notes

Select this component when a compact active solution for 3x frequency multiplication is required. The fixed output range of 1350 MHz to 1800 MHz suits applications needing precise harmonic generation. Evaluate the 9 dB conversion gain against system loss budgets to ensure adequate signal levels.

Part Context

This part belongs to the Pasternack MHV series of RF components. It serves as a specialized signal conditioning module distinct from passive coaxial connectors or cable assemblies. The product integrates active semiconductor technology to perform frequency translation tasks within microwave engineering contexts.

Replacement Considerations

No public confirmed substitute part numbers are available for this specific model.
