PE88X2024

Overview

The Pasternack PE88X2024 is a WR-12 waveguide active frequency multiplier designed for E-band applications. It operates with an output frequency range of 60 GHz to 90 GHz and delivers a typical output power of +15 dBm. The device features an SMA input interface for signal injection into the waveguide structure. This component functions as a critical element in high-frequency signal generation chains, converting lower input frequencies to the specified millimeter-wave output band while maintaining signal integrity within the designated power parameters.

Feature Summary

• Utilizes WR-12 waveguide architecture for efficient high-frequency signal transmission
• Provides active frequency multiplication to generate E-band output signals
• Integrates an SMA connector interface for standard input signal coupling

Applications

• E-band wireless communication systems
• Millimeter-wave test and measurement instrumentation
• High-frequency radar subsystems

Procurement Notes

Verify the specific datasheet version and technical specifications directly from the manufacturer or authorized distributor before procurement. Confirm that the SMA input interface and WR-12 waveguide dimensions align with your system requirements. Ensure environmental operating conditions meet the intended application standards. Cross-reference the part number to avoid confusion with similar multiplier models.

Selection Notes

Select this component when an E-band output frequency range between 60 GHz and 90 GHz is required. Consider the +15 dBm output power capability relative to downstream load requirements. Evaluate the SMA input compatibility against existing source equipment. Assess the WR-12 waveguide form factor for integration into the physical layout of the microwave assembly.

Part Context

This model belongs to Pasternack's portfolio of active frequency multipliers targeting millimeter-wave spectrum utilization. It addresses the need for compact, high-performance frequency conversion solutions in the E-band region. The product represents a specialized solution for engineers requiring reliable signal generation at these high frequencies without complex external synthesis architectures.
