PEC16DBAN

Headers, Male Pins Overview

The PEC16DBAN is a male board-to-board connector header manufactured by Sullins Connector Solutions. It features a single row of 32 positions with a 0.100 inch (2.54mm) pitch. The component utilizes through-hole right-angle mounting for secure PCB integration. Contact materials consist of phosphor bronze with gold plating on the mating surfaces and tin plating on the termination pins. The insulator is constructed from polybutylene terephthalate (PBT), rated UL94 V-0, supporting an operating temperature range of -65°C to 125°C.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting configuration for space-efficient board connections
• Gold-plated phosphor bronze contacts ensure reliable signal transmission
• Unshrouded breakaway design allows for flexible assembly and customization

Headers, Male Pins Applications

• Industrial control system interconnects
• Consumer electronics internal circuit boards
• Telecommunications equipment modules

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against the manufacturer's official datasheet to confirm exact pin count, plating thickness, and material specifications. Ensure compatibility with existing PCB footprint dimensions and thermal requirements during the sourcing process.

Headers, Male Pins Selection Notes

Select this component when a right-angle male header with a standard 2.54mm pitch is required. Consider the unshrouded design for applications where space constraints necessitate a low-profile connection without side walls.

Headers, Male Pins Part Context

This part belongs to the PEC series of rectangular connectors from Sullins Connector Solutions. The series offers various configurations including straight and right-angle headers in multiple row counts and pitches, catering to diverse electronic interconnection needs.

Headers, Male Pins Replacement Considerations

Cross-reference with similar right-angle male headers from other manufacturers ensuring identical 0.100 inch pitch, 32-position count, and through-hole mounting style to maintain mechanical and electrical compatibility.
