PEC18DBCN

Headers, Male Pins Overview

The PEC18DBCN is a male header connector manufactured by Sullins Connector Solutions. It features 36 positions arranged in a single row with a 0.100-inch (2.54mm) pitch. Designed for through-hole mounting, the contacts are made of phosphor bronze with a tin plating finish. The insulating material is polybutylene terephthalate (PBT), rated UL94 V-0. The connector supports a current rating of 3A and operates within a temperature range of -65°C to 125°C.

Headers, Male Pins Feature Summary

• Male breakaway header design allows for separation from carrier boards after assembly.
• Right-angle installation facilitates compact board-to-board or cable connections.
• Push-pull fastening type ensures secure mating stability.

Headers, Male Pins Applications

• Board-to-board interconnects
• Cable-to-board connections
• General electronic equipment internal wiring

Headers, Male Pins Procurement Notes

Verify that the specific part number PEC18DBCN matches the required 36-position count and right-angle orientation. Confirm that the tin-plated contact finish meets the environmental requirements for the intended application. Ensure the PBT insulation material and UL94 V-0 flammability rating align with safety standards. Check compatibility with standard through-hole soldering processes.

Headers, Male Pins Selection Notes

Select this component when a right-angle male header with a 2.54mm pitch is required. The 36-position configuration suits applications needing moderate density. The push-pull feature aids in manual assembly. Verify that the 3A current rating and -65°C to 125°C operating range cover the system's electrical and thermal demands.

Headers, Male Pins Part Context

This component belongs to the PEC series of male headers from Sullins Connector Solutions. The series offers various position counts and configurations. The PEC18DBCN specifically provides a right-angle solution for reliable signal transmission in space-constrained designs.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult manufacturer catalogs for cross-references if needed.
