PEC2305S1Q_R1_00001

PEC2305S1Q_R1_00001 is listed in the Tvs Diodes range at ChipApex. The manufacturer field lists Panjit International Inc.. Its product description is TVS DIODE 5VWM 15VC DFN06032. Review the specifications below when checking this part for your BOM.

Tvs Diodes specifications for PEC2305S1Q_R1_00001

• Description：TVS DIODE 5VWM 15VC DFN06032
• Series：-
• Mfr：Panjit International Inc.
• Package：Tape & Reel (TR),Cut Tape (CT)
• Type：Zener
• Bidirectional Channels：1
• Voltage - Reverse Standoff (Typ)：5V (Max)
• Voltage - Breakdown (Min)：5.5V
• Voltage - Clamping (Max) @ Ipp：15V
• Current - Peak Pulse (10/1000µs)：2A (8/20µs)
• Power - Peak Pulse：-
• Power Line Protection：No
• Applications：General Purpose
• Capacitance @ Frequency：3.5pF @ 1MHz (Max)
• Operating Temperature：-55°C ~ 150°C (TJ)
• Mounting Type：Surface Mount
• Package / Case：0201 (0603 Metric)
• Supplier Device Package：DFN0603-2
• Unidirectional Channels：-
• Grade：-
• Qualification：-

Tvs Diodes datasheet and documents for PEC2305S1Q_R1_00001
