PEC26DADN

$3.29

Description：CONN HEADER VERT 52POS 2.54MM
Series：-
Mfr：Sullins Connector Solutions
Package：Bulk

SKU:26a25fde9f16 Category: Headers, Male Pins Brand: Sullins Connector Solutions

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PEC26DADN is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Sullins Connector Solutions. Its product description is CONN HEADER VERT 52POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for PEC26DADN

Description：CONN HEADER VERT 52POS 2.54MM
Series：-
Mfr：Sullins Connector Solutions
Package：Bulk
Connector Type：Header, Breakaway
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：52
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.230" (5.84mm)
Contact Length - Post：0.420" (10.67mm)
Overall Contact Length：0.750" (19.05mm)
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：100.0µin (2.54µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Polybutylene Terephthalate (PBT)
Features：-
Operating Temperature：-65°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：-

Headers, Male Pins datasheet and documents for PEC26DADN

PEC26DADN

Headers, Male Pins Overview

The PEC26DADN is a male header connector manufactured by Sullins Connector Solutions. It features 26 positions arranged in a single row with a 0.100 inch (2.54 mm) pitch. The connector utilizes breakaway pins for versatile deployment and employs tin plating on the contact surfaces. Designed for through-hole termination, it supports vertical board-to-board or cable connections. The unit incorporates a push-pull fastening mechanism and operates within a temperature range of -65°C to 125°C.
