PFC2225BNP-402

$2.64

Description：CMC 4MH 4A 2LN TH
Series：PFC
Mfr：Sumida America Components Inc.
Package：Bulk

SKU:e2742d31aa66 Category: Common Mode Chokes Brand: Sumida America Components Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PFC2225BNP-402 is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists Sumida America Components Inc.. Its product description is CMC 4MH 4A 2LN TH. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for PFC2225BNP-402

Description：CMC 4MH 4A 2LN TH
Series：PFC
Mfr：Sumida America Components Inc.
Package：Bulk
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：4A
DC Resistance (DCR) (Max)：54mOhm
Voltage Rating - DC：-
Voltage Rating - AC：250V
Operating Temperature：-40°C ~ 85°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.984" L x 0.787" W (25.00mm x 20.00mm)
Height (Max)：1.063" (27.00mm)
Package / Case：Vertical, No Base, 4 PC Pin
Inductance @ Frequency：4 mH @ 1 kHz
Impedance @ Frequency：-

Common Mode Chokes datasheet and documents for PFC2225BNP-402

PFC2225BNP-402

Common Mode Chokes Overview

The PFC2225BNP-402 is a two-line common mode choke manufactured by Sumida America Components Inc. It features an inductance of 4 mH measured at 1 kHz and supports a maximum DC current of 4 A. The component has a maximum DC resistance (DCR) of 54 mOhms. Physical dimensions are 25 mm in length, 20 mm in width, and 27 mm in height. It operates within a temperature range of -40°C to +85°C and utilizes through-hole vertical mounting.

Common Mode Chokes Feature Summary

Provides common mode noise suppression for power lines
Designed for vertical through-hole PCB mounting
Utilizes a robust core structure for high current handling

Common Mode Chokes Applications

Power line filtering in electronic equipment
Noise suppression in AC/DC power supplies
EMI reduction in industrial control systems

Common Mode Chokes Procurement Notes

Verify the specific manufacturing date code and RoHS compliance status directly with the supplier or manufacturer before procurement. Confirm that the through-hole footprint dimensions match the target PCB layout. Ensure the 4 A current rating meets the operational requirements of the specific circuit application to prevent saturation or overheating during peak load conditions.

Common Mode Chokes Selection Notes

Select this component when a high-inductance common mode choke is required for power line applications. The 4 mH value provides significant attenuation for common mode noise. Verify that the physical size of 25x20x27 mm fits within the available enclosure space. Ensure the operating temperature range of -40°C to +85°C aligns with the environmental conditions of the final assembly.

Common Mode Chokes Part Context

This part belongs to the PFC series of common mode chokes from Sumida. It is designed for general-purpose power line filtering. The component uses a vertical through-hole construction suitable for standard PCB assembly processes. It serves as a passive filter element to mitigate electromagnetic interference in electrical circuits.
