PG0871.682NLT

$0.94

Description：FIXED IND 6.8UH 5.8A 20 MOHM SMD
Series：PG0871NL
Mfr：Pulse Electronics
Package：Tape & Reel (TR)

SKU:5e2964915df4 Category: Fixed Inductors Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PG0871.682NLT is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is FIXED IND 6.8UH 5.8A 20 MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for PG0871.682NLT

Description：FIXED IND 6.8UH 5.8A 20 MOHM SMD
Series：PG0871NL
Mfr：Pulse Electronics
Package：Tape & Reel (TR)
Type：Wirewound
Material - Core：-
Inductance：6.8 µH
Tolerance：±20%
Current Rating (Amps)：5.8 A
Current - Saturation (Isat)：7.8A
Shielding：Shielded
DC Resistance (DCR)：20mOhm
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 130°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.299" L x 0.291" W (7.60mm x 7.40mm)
Height - Seated (Max)：0.252" (6.40mm)
Features：-

Fixed Inductors datasheet and documents for PG0871.682NLT

PG0871.682NLT

Fixed Inductors Overview

The PG0871.682NLT is a shielded wirewound power inductor from Pulse Electronics, designed for surface-mount applications. It features an inductance of 6.8 µH with a tolerance of ±20%. The component has a maximum DC resistance (DCR) of 20 mOhm and supports a rated current of 5.8 A, with a saturation current (Isat) of 7.8 A. Measuring 7.60 mm x 7.40 mm with a maximum height of 6.40 mm, it operates within a temperature range of -40°C to 130°C and is tested at 100 kHz.

Fixed Inductors Feature Summary

Shielded wirewound construction minimizes electromagnetic interference.
High saturation current capability for stable performance under load.
Low DC resistance reduces power loss and heat generation.

Fixed Inductors Applications

Point-of-load voltage regulation modules
DC-DC converter output filtering
Power supply input chokes

Fixed Inductors Procurement Notes

Verify the manufacturer part number against official Pulse Electronics documentation to ensure authenticity. Confirm that the specific suffix matches the required electrical parameters. Check RoHS compliance status as per the latest datasheet revisions. Ensure storage conditions align with moisture sensitivity level requirements before assembly.

Fixed Inductors Selection Notes

Select this component when high current handling and low DCR are critical for efficiency. The shielded design is suitable for space-constrained boards requiring EMI reduction. Compare saturation current ratings against peak load requirements to prevent inductance drop. Verify footprint compatibility with existing PCB layout constraints.

Fixed Inductors Part Context

This part belongs to the PG0871NL series of fixed inductors. It is categorized under power inductors and chokes. The series offers various inductance values tailored for different current requirements while maintaining a consistent footprint family for design flexibility.
