PHA2729-240M

Overview

The PHA2729-240M is a pulsed power module manufactured by MACOM Technology Solutions. It operates within the frequency range of 2.7 GHz to 2.9 GHz and delivers an output power of 240 W. The component is designed for radar applications requiring high peak power performance. It utilizes a module package configuration suitable for surface mount installation. The device supports general purpose RF functions and is compliant with RoHS3 standards.

Feature Summary

• Delivers 240 W pulsed output power
• Operates in the 2.7 GHz to 2.9 GHz band
• Designed for radar pulsed power applications

Applications

• Radar systems
• Pulsed power transmission
• Military communication links

Procurement Notes

Verify the specific datasheet revision and physical dimensions against the design requirements before integration. Confirm that the thermal management solution aligns with the module's heat dissipation needs. Ensure the driving circuitry can support the required pulse parameters. Check for any recent product change notices regarding assembly sites or materials. Validate compliance with export control classifications EAR99 for the intended destination.

Selection Notes

Select this module when a compact, high-power pulsed source is needed for S-band radar operations. Consider the module form factor for PCB layout constraints. Evaluate the duty cycle capabilities against system thermal limits. Compare performance metrics with alternative discrete solutions for size and efficiency trade-offs. Ensure the input drive levels match the module's specifications for optimal power output.

Part Context

This part belongs to MACOM's portfolio of radio frequency and microwave components. The company specializes in high-performance analog semiconductor solutions for defense and industrial markets. The PHA2729-240M represents a packaged solution for generating significant RF energy in pulsed modes. It integrates active devices into a robust module structure for reliability.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
