PHBC24W-2R1B0065V

$43.02

Description：CMC 65UH 30A 2LN TH
Series：PHBC
Mfr：KEMET
Package：Bulk

SKU:2664be3eaba3 Category: Common Mode Chokes Brand: KEMET

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PHBC24W-2R1B0065V is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists KEMET. Its product description is CMC 65UH 30A 2LN TH. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for PHBC24W-2R1B0065V

Description：CMC 65UH 30A 2LN TH
Series：PHBC
Mfr：KEMET
Package：Bulk
Filter Type：-
Number of Lines：2
Current Rating (Max)：30A
DC Resistance (DCR) (Max)：6.2mOhm
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 125°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：2.268" Dia (57.60mm)
Height (Max)：-
Package / Case：Vertical, No Base, 2 PC Pin
Inductance @ Frequency：65 µH @ 100 kHz
Impedance @ Frequency：-

Common Mode Chokes datasheet and documents for PHBC24W-2R1B0065V

PHBC24W-2R1B0065V

Common Mode Chokes Overview

The KEMET PHBC24W-2R1B0065V is a leaded common mode choke utilizing a Fe-Ni dust core material. It features a toroidal design with a nominal inductance of 65 µH and a tolerance of 20%. The component supports a maximum current rating of 30 A and exhibits a DC resistance (DCR) of 6.2 mΩ. Designed for through-hole mounting, it operates within a temperature range of -40°C to +125°C.

Common Mode Chokes Feature Summary

Utilizes Fe-Ni dust core material for low core loss and high saturation magnetic flux density
Toroidal construction optimized for big current applications
Through-hole mounting configuration

Common Mode Chokes Applications

High current power filtering circuits
Common mode noise suppression in industrial equipment
Power supply input stages requiring robust current handling

Common Mode Chokes Procurement Notes

Verify the specific datasheet version and RoHS compliance status directly with KEMET or authorized distributors, as environmental certifications may vary by production batch. Confirm that the through-hole package dimensions and pin spacing match your PCB layout requirements before finalizing procurement decisions.

Common Mode Chokes Selection Notes

Select this component when high current capacity (30 A) and low impedance are critical for EMI suppression. The Fe-Ni core offers superior performance in high-saturation scenarios compared to standard ferrite cores. Ensure the operating environment stays within the specified -40°C to +125°C range for reliable operation.

Common Mode Chokes Part Context

This part belongs to the KEMET PHBC series of leaded common mode chokes. The series is characterized by its use of advanced dust core materials to handle significant current loads while maintaining effective noise filtration. It serves as a specialized solution for power integrity in demanding electronic systems.
